Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Size : Seamless Elbow ( 1/2″～24″), ERW / Welded / Fabricated Elbow (1/2″～48″)
Type : Seamless / ERW / Welded / Fabricated
Thickness : Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc.
Form : Elbow, 90 Deg Elbow, Long Radius Elbow, Short Radius Elbow, LR Elbow, SR Elbow.
Related News
|
Nominal |
Outside Diameter |
Center to End |
|||||||||
|
Long Radius Elbows |
Short Radius Elbows |
||||||||||
|
90 degree |
45 degree |
90 degree |
45 degree |
||||||||
|
-- |
-- |
||||||||||
| 1/2 |
21.3 |
38.1 |
15.7 |
|
|
||||||
|
3/4 |
26.7 |
38.1 |
19.1 |
-- |
-- |
||||||
|
1 |
33.4 |
38.1 |
22.4 |
25.4 |
-- |
||||||
|
1-1/4 |
42.2 |
47.8 |
25.4 |
31.8 |
-- |
||||||
|
1-1/2 |
48.3 |
57.2 |
28.4 |
38.1 |
-- |
||||||
|
2 |
60.3 |
76.2 |
35.1 |
50.8 |
-- |
||||||
|
2-1/2 |
73.0 |
95.2 |
44.4 |
63.5 |
-- |
||||||
|
3 |
88.9 |
114.3 |
50.8 |
76.2 |
31.6 |
||||||
|
3-1/2 |
101.6 |
133.4 |
57.2 |
88.9 |
36.8 |
||||||
|
4 |
114.3 |
152.4 |
63.5 |
101.6 |
42.1 |
||||||
|
5 |
141.3 |
190.5 |
79.2 |
127.0 |
52.6 |
||||||
|
6 |
168.3 |
228.6 |
95.2 |
152.4 |
63.4 |
||||||
|
8 |
219.1 |
304.8 |
127.0 |
203.2 |
84.2 |
||||||
|
10 |
273.1 |
381.0 |
158.8 |
254.0 |
105.2 |
||||||
|
12 |
323.9 |
457.2 |
190.5 |
304.8 |
126.3 |
||||||
|
14 |
355.6 |
533.4 |
222.2 |
355.6 |
147.3 |
||||||
|
16 |
406.4 |
609.6 |
254.0 |
406.4 |
168.3 |
||||||
|
18 |
457.2 |
685.8 |
285.8 |
457.2 |
189.4 |
||||||
|
20 |
508.0 |
762.0 |
317.5 |
508.0 |
210.4 |
||||||
|
22 |
558.8 |
838.2 |
342.9 |
558.8 |
231.5 |
||||||
|
24 |
609.6 |
914.4 |
381.0 |
609.6 |
252.5 |
||||||
|
26 |
660.4 |
990.6 |
406.4 |
660.4 |
273.5 |
||||||
|
28 |
711.2 |
1066.8 |
438.2 |
711.2 |
294.6 |
||||||
|
30 |
762.0 |
1143.0 |
469.9 |
762.0 |
315.6 |
||||||
|
32 |
812.8 |
1219.2 |
501.6 |
812.8 |
378.1 |
||||||
|
34 |
863.6 |
1295.4 |
533.4 |
863.6 |
357.7 |
||||||
|
36 |
914.4 |
1371.6 |
565.2 |
914.4 |
378.8 |
||||||
|
38 |
965.2 |
1447.8 |
599.9 |
-- |
-- |
||||||
|
40 |
1016.0 |
1524.0 |
632.0 |
1016.0 |
420.8 |
||||||
|
42 |
1066.8 |
1600.2 |
660.4 |
1066.8 |
441.9 |
||||||
|
44 |
1117.6 |
1676.4 |
695.5 |
1117.6 |
462.9 |
||||||
|
46 |
1168.4 |
1752.6 |
726.9 |
-- |
-- |
||||||
|
48 |
1219.2 |
1828.8 |
759.0 |
1219.2 |
505.0 |
||||||
|
52 |
1320.8 |
-- |
-- |
1320.8 |
547.1 |
||||||
|
54 |
1371.6 |
2057.4 |
852.2 |
1371.6 |
568.1 |
||||||
|
56 |
1422.4 |
2133.6 |
883.8 |
1422.4 |
589.2 |
||||||
|
60 |
1524.0 |
2286.0 |
946.9 |
1524.0 |
631.3 |
||||||
|
66 |
1676.4 |
2514.6 |
1041.6 |
-- |
-- |
||||||
|
68 |
1727.0 |
2591 |
1073 |
1727 |
-- |
||||||
|
72 |
1829.0 |
2743 |
1137 |
1829 |
-- |
||||||
|
76 |
1930.0 |
2896 |
1199 |
1930 |
-- |
||||||
|
80 |
2032.0 |
3048 |
1263 |
2032 |
-- |
||||||
