Dimensions of JIS B2220 5K flange for accurate installation and compatibility considerations.

JIS B2220 5K flanges are widely used in the piping industry for connecting pipes, valves, and other equipment. These flanges are designed to withstand low-pressure applications, with a pressure rating of 5 kilograms per square centimeter. Understanding the dimensions of JIS B2220 5K flanges is crucial for ensuring proper installation and assembly in a piping system. The dimensions of JIS B2220 5K flanges are standardized by the Japanese Industrial Standards (JIS), and they come in various sizes ranging from DN10 to DN2000. The flanges are available in different materials such as carbon steel, stainless steel, and alloy steel to suit the requirements of different applications. When it comes to the dimensions of JIS B2220 5K flanges, there are several key measurements to consider. These include the outside diameter, inner diameter, bolt circle diameter, bolt hole diameter, bolt hole number, thickness, and height of the flange. All these dimensions are specified in the JIS B2220 standard to ensure interchangeability and compatibility with other components in the piping system. The outside diameter of a JIS B2220 5K flange is the diameter of the flange from one outer edge to the opposite outer edge. The inner diameter, on the other hand, refers to the diameter of the opening or bore inside the flange where the pipe is inserted

jis b2220 5k flange dimensions. The bolt circle diameter is the diameter of the circle that passes through the center of all the bolt holes on the flange. This measurement is crucial for determining the spacing and alignment of the bolts during installation. The bolt hole diameter is the diameter of the holes on the flange where the bolts are inserted to secure the flange to the pipe or equipment. The number of bolt holes and their arrangement is also specified in the JIS B2220 standard to ensure proper alignment and distribution of the load on the flange. The thickness of a JIS B2220 5K flange is the distance between the facing surfaces of the flange. This measurement is important for determining the strength and rigidity of the flange to withstand the pressure and temperature conditions in the piping system. The height of the flange is the total height of the flange from the bottom to the top surface. In conclusion, understanding the dimensions of JIS B2220 5K flanges is essential for selecting the right flange for your piping system and ensuring proper installation and assembly. By following the specifications and guidelines outlined in the JIS B2220 standard, you can ensure the reliable and efficient operation of your piping system.
