From JIS to ANSI: How Butt Welding Pipe Fittings Meet Global Standards for Industrial Applications


In the global landscape of industrial piping systems, butt welding pipe fittings stand as core components that connect different pipelines and ensure efficient fluid transmission. From Japan's JIS to the US ANSI, and from Europe's EN to Russia's GOST, YULONG Steel, a professional buttweld fittings manufacturer, has always taken multi-standard compliance as its cornerstone, providing safe and versatile connection solutions for industries such as oil & gas, chemicals, and energy. This article decodes the technical requirements of different international standards and how stainless steel butt weld pipe fittings transcend geographical boundaries to become the "universal language" of global industrial pipelines.

International Standards: The "Global Passport" for Butt Welding Pipe Fittings



ANSI/ASME B16.9: The Stringent Benchmark for North American Industry



The ANSI standard is renowned for its adaptability to high-pressure scenarios, mandating that butt welding pipe fittings adhere strictly to ASME specifications for wall thickness, bevel angles (e.g., 37°±2°), and heat treatment processes. For example, a PN63 elbow used in shale gas extraction must undergo 100% radiographic testing (RT) to ensure no cracks at -40°C. YULONG Steel's ANSI-series fittings come standard with NACE MR0175 certification, enhancing resistance to hydrogen sulfide corrosion by 20% compared to conventional products, making them the designated choice for deep-sea platforms in the Gulf of Mexico.



JIS B2311: The Epitome of Japanese Industrial Precision



The JIS standard emphasizes "millimeter-level accuracy," such as a DN50 JIS 10K elbow with an outer diameter tolerance of ±0.2mm and a flange face parallelism error ≤0.1mm. This precision makes it indispensable in ultrapure water pipelines of semiconductor wafer factories—stainless steel butt weld pipe fittings undergo electrolytic polishing (Ra≤0.4μm) on the inner wall to avoid ion contamination, meeting the stringent cleanliness requirements of SEMI F20.



EN 10253-2: The Safety Barrier for European Pressure Equipment



EN-compliant butt welding pipe fittings must pass the PED 2014/68/EU certification. For instance, a 316L stainless steel tee used in chemical reactors must simulate 1,000 thermal cycles (-20°C~450°C) to verify fatigue resistance. YULONG Steel's EN-series products employ a full-process digital traceability system, with data from 27 manufacturing steps—from steelmaking to finishing—available for online query, ensuring full quality traceability for each fitting.



Material Innovation of YULONG Steel Butt Weld Pipe Fittings



Stainless Steel Butt Weld Pipe Fittings: The Preferred Choice for Corrosion-Resistant Scenarios



Among grades like JIS SUS304, ANSI 316L, and EN 1.4404, YULONG Steel's stainless steel butt weld pipe fittings optimize the duplex structure (ferrite: austenite 45:55), increasing the pitting resistance equivalent number (PREN) to 32, suitable for seawater desalination projects with chloride ions. For example, a DN1000 stainless steel elbow supplied to a Middle Eastern LNG terminal showed a corrosion depth <0.05mm after 1,000 hours of salt spray testing, far exceeding ASTM B117 standards.



Carbon Steel and Alloy Steel: The Standards for High-Pressure Scenarios



For ANSI A234 WPB carbon steel tees (suitable for steam pipelines below 200°C) and EN 1.0481 alloy steel reducers (resistant to 550°C high temperatures), YULONG Steel applies normalizing and tempering treatments, increasing Charpy V impact toughness by 30%. These fittings have operated stably for 8 years in supercritical units of a Russian Far East thermal power plant without any cracks or deformation.



Process Upgrades of YULONG Steel Butt Weld Pipe Fittings



Bevel Design: The Key Bridge for Cross-Standard Connections



Different standard bevel forms (e.g., ANSI V-type, JIS UV-type, EN double V-type) require computer-aided engineering (CAE) to optimize penetration depth, ensuring tensile strength of welded joints ≥95% of the base material. YULONG Steel's intelligent beveling machine automatically switches 12 types of cutters to achieve ±1° angle accuracy, solving the adaptation challenge of "one project, multiple standards" in transnational projects.



Nondestructive Testing: The Hardcore Support for Multi-Standard Certification



From ANSI-required liquid penetrant testing (LPT) to EN-specified ultrasonic testing (UT), each butt welding pipe fitting undergoes at least 3 NDT tests. For example, a DN600 stainless steel flange produced for a Brazilian petroleum company uses time-of-flight diffraction (TOFD) to detect defects as small as 0.5mm, meeting API 5L requirements for subsea pipelines.



YULONG Steel Buttweld Fittings Manufacturer



As a buttweld fittings manufacturer with 20 years of experience in global markets, YULONG Steel has built an intelligent system of "standard database + flexible production line":



Standard Database: Integrates 12 national standards including ANSI, JIS, EN, and GOST, with real-time updates on technical parameters and certification requirements;

Flexible Production Line: Achieves full-size coverage from DN15 to DN2000 through AGV robots and CNC machine linkage, reducing changeover time to 30 minutes;

Global Certifications: Holds 28 international certifications such as CE/PED, API 5L, and JIS MARK, exporting products to 60+ countries to adapt to industrial pipe networks worldwide.



When butt-welding pipe fittings bridge geographical boundaries—connecting North American shale gas fields with Middle Eastern refineries, Japanese semiconductor factories with European photovoltaic power stations—they embody a deep understanding of multi-standard technology. YULONG Steel's stainless steel butt weld pipe fittings, carbon steel, and alloy steel products are not just physical connectors in piping systems but also technical links between different industrial civilizations.



Contact us today to obtain multi-standard compliant butt welding pipe fitting solutions, ensuring every connection meets the highest global industrial expectations.
